Product Details:
| Minimum Order Quantity | 20 Piece |
| Pole Type | Octagonal Pole |
| Material | Mild Steel |
| Brand | Kasper |
| Height | 4 Meter |
| Usage/Application | Street |
| Features | Hot Dip Galvanized. |
| Bottom Size | 130 A/F mm |
| Top Size | 70 A/F mm |
| Base Plate Size | 200 x 200 x 12 mm (L x W x T) |
| Product Code | KOP04 |
Our specifically engineered Galvanized Octagonal Pole are manufactured with duly segregated and procured top class raw materials. We do not compromise the quality of raw-material at all, we rather manufacture this product owing to deliver prolonged durability.
Corrosion resistance, easy installation and trendy outlook are few attractive features to look out for in our octagonal poles. The poles are duly fabricated from Iron and steel which offers strong structure. The poles primary utilization is for street lighting purposes and for installation of wires.
The poles assure safety and visibility all throughout and can be designed as per specific requirements laid down by the client. Be it any color or size, you name it we will provide it.
We also design Galvanized Octagonal Poles as per the client's requirement within minimum quantity order.
Specifications:
| Pole Type | Height (Meter) | Top Diameter (mm) | Bottom Dia. (mm) | Sheet Thickness (mm) | Base Plate mm (L x W x T) | Foundation Bolt (No. xDiaxmm) |
| KOP03 | 3 | 70 | 130 | 3 | 200 x 200 x 12 | 4 x 16 x 450 |
| KOP05 | 5 | 70 | 130 | 3 | 200 x 200 x 12 | 4 x 16 x 450 |
| KOP06 | 6 | 70 | 130 | 3 | 200 x 200 x 12 | 4 x 16 x 600 |
| KOP07 | 7 | 70 | 130 | 3 | 220 x 220 x 12 | 4 x 20 x 600 |
| KOP08 | 8 | 70 | 135 | 3 | 225 x 225 x 12 | 4 x 20 x 700 |
| KOP09 | 9 | 70 | 155 | 3 | 250 x 250 x 12 | 4 x 20 x 700 |
| KOP010 | 10 | 70 | 155 | 3 | 250 x 250 x 16 | 4 x 24 x 750 |
| KOP011 | 11 | 70 | 175 | 3 | 275 x 275 x 16 | 4 x 24 x 750 |
| KOP012 | 12 | 70 | 175 | 3 | 275 x 275 x 16 | 4 x 24 x 750 |
| KOP013 | 13 | 125 | 270 | 3 | 340 x 340 x 20 | 4 x 24 x 900 |
Additional Information:
Product Details:
| Pole Type | Octagonal Poles |
| Material | Mild Steel |
| Height | 10 Meter |
| Usage/Application | Highway |
| Surface Finish | Hot Dip Galvanized |
| Bottom Size | 155 A/F mm |
| Plate Thickness Mm | 3 mm |
| Product Code | KOP010 |
| Top Size | 70 A/F mm |
| Base Plate Size | 250 x 250 x 16 mm |
| Pole Type | Height (Meter) | Top Diameter (mm) | Bottom Dia. (mm) | Sheet Thickness (mm) | Base Plate mm (L x W x T) | Foundation Bolt (No. xDiaxmm) |
| KOP03 | 3 | 70 | 130 | 3 | 200 x 200 x 12 | 4 x 16 x 450 |
| KOP04 | 4 | 70 | 130 | 3 | 200 x 200 x 12 | 4 x 16 x 450 |
| KOP05 | 5 | 70 | 130 | 3 | 200 x 200 x 12 | 4 x 16 x 450 |
| KOP06 | 6 | 70 | 130 | 3 | 200 x 200 x 12 | 4 x 16 x 600 |
| KOP09 | 9 | 70 | 155 | 3 | 250 x 250 x 12 | 4 x 20 x 700 |
| KOP011 | 11 | 70 | 175 | 3 | 275 x 275 x 16 | 4 x 24 x 750 |
| KOP012 | 12 | 70 | 175 | 3 | 275 x 275 x 16 | 4 x 24 x 750 |
| KOP013 | 13 | 125 | 270 | 3 | 340 x 340 x 20 | 4 x 24 x 900 |
Product Details:
| Minimum Order Quantity | 20 Piece |
| Pole Type | Octagonal Poles |
| Material | Mild Steel |
| Height | 6 Meter |
| Usage/Application | Highway |
| Surface Finish | Hot Dip Galvanized |
| Bottom Size | 130 A/F mm |
| Plate Thickness Mm | 3 mm |
| Product Code | KOP06 |
| Base Plate Size | 200 x 200 x 12 mm (L x W x T) |
| Top Size | 70 A/F mm |
| Country of Origin | Made in India |
| Pole Type | Height (Meter) | Top Diameter (mm) | Bottom Dia. (mm) | Sheet Thickness (mm) | Base Plate mm (L x W x T) | Foundation Bolt (No. xDiaxmm) |
| KOP03 | 3 | 70 | 130 | 3 | 200 x 200 x 12 | 4 x 16 x 450 |
| KOP04 | 4 | 70 | 130 | 3 | 200 x 200 x 12 | 4 x 16 x 450 |
| KOP05 | 5 | 70 | 130 | 3 | 200 x 200 x 12 | 4 x 16 x 450 |
| KOP07 | 7 | 70 | 130 | 3 | 220 x 220 x 12 | 4 x 20 x 600 |
| KOP08 | 8 | 70 | 135 | 3 | 225 x 225 x 12 | 4 x 20 x 700 |
| KOP09 | 9 | 70 | 155 | 3 | 250 x 250 x 12 | 4 x 20 x 700 |
| KOP010 | 10 | 70 | 155 | 3 | 250 x 250 x 16 | 4 x 24 x 750 |
| KOP011 | 11 | 70 | 175 | 3 | 275 x 275 x 16 | 4 x 24 x 750 |
| KOP012 | 12 | 70 | 175 | 3 | 275 x 275 x 16 | 4 x 24 x 750 |
| KOP013 | 13 | 125 | 270 | 3 | 340 x 340 x 20 | 4 x 24 x 900 |
Additional Information:
Product Details:
| Pole Type | Octagonal Pole |
| Brand | Kasper |
| Material | Mild Steel |
| Height | 3 Meter |
| Usage/Application | Street and Highways |
| Surface Finish | Hot Dip Galvanized |
| Bottom Size | 130 A/F mm |
| Base Plate Size | 220 x 220 x 12 mm |
| Top Size | 70 A/F mm |
| Product Code | KOP03 |
| Pole Type | Height (Meter) | Top Diameter (mm) | Bottom Dia. (mm) | Sheet Thickness (mm) | Base Plate mm (L x W x T) | Foundation Bolt (No. xDiaxmm) |
| KOP04 | 4 | 70 | 130 | 3 | 200 x 200 x 12 | 4 x 16 x 450 |
| KOP05 | 5 | 70 | 130 | 3 | 200 x 200 x 12 | 4 x 16 x 450 |
| KOP06 | 6 | 70 | 130 | 3 | 200 x 200 x 12 | 4 x 16 x 600 |
| KOP07 | 7 | 70 | 130 | 3 | 220 x 220 x 12 | 4 x 20 x 600 |
| KOP08 | 8 | 70 | 135 | 3 | 225 x 225 x 12 | 4 x 20 x 700 |
| KOP09 | 9 | 70 | 155 | 3 | 250 x 250 x 12 | 4 x 20 x 700 |
| KOP010 | 10 | 70 | 155 | 3 | 250 x 250 x 16 | 4 x 24 x 750 |
| KOP011 | 11 | 70 | 175 | 3 | 275 x 275 x 16 | 4 x 24 x 750 |
| KOP012 | 12 | 70 | 175 | 3 | 275 x 275 x 16 | 4 x 24 x 750 |
| KOP013 | 13 | 125 | 270 | 3 | 340 x 340 x 20 | 4 x 24 x 900 |
Additional Information:
Product Details:
| Pole Type | Octagonal Poles |
| Material | Mild Steel |
| Height | 12 Meter |
| Usage/Application | Highway |
| Surface Finish | Hot Dip Galvanized |
| Pole Bottom Size | 175 A/F mm |
| Base Plate Size | 275 x 275 x 16 mm (L x W x T) |
| Product Code | KOP012 |
| Thickness | 3 mm |
| Pole Top Size | 70 A/F mm |
| Pole Type | Height (Meter) | Top Diameter (mm) | Bottom Dia. (mm) | Sheet Thickness (mm) | Base Plate mm (L x W x T) | Foundation Bolt (No. xDiaxmm) |
| KOP03 | 3 | 70 | 130 | 3 | 200 x 200 x 12 | 4 x 16 x 450 |
| KOP04 | 4 | 70 | 130 | 3 | 200 x 200 x 12 | 4 x 16 x 450 |
| KOP05 | 5 | 70 | 130 | 3 | 200 x 200 x 12 | 4 x 16 x 450 |
| KOP06 | 6 | 70 | 130 | 3 | 200 x 200 x 12 | 4 x 16 x 600 |
| KOP09 | 9 | 70 | 155 | 3 | 250 x 250 x 12 | 4 x 20 x 700 |
| KOP010 | 10 | 70 | 155 | 3 | 250 x 250 x 16 | 4 x 24 x 750 |
| KOP011 | 11 | 70 | 175 | 3 | 275 x 275 x 16 | 4 x 24 x 750 |
| KOP013 | 13 | 125 | 270 | 3 | 340 x 340 x 20 | 4 x 24 x 900 |
Product Details:
| Pole Type | Octagonal Pole |
| Material | Mild Steel |
| Height | 5 Meter |
| Usage/Application | Highways |
| Surface Finish | Hot Dip Galvanized |
| Bottom Size | 130 A/F mm |
| Plate Thickness Mm | 3 mm |
| Top Size | 70 A/F mm |
| Brand | Kasper |
| Product Code | KOP05 |
| Base Plate | 200 x 200 x 12 mm (L x W x T) |
| Country of Origin | Made in India |
| Pole Type | Height (Meter) | Top Diameter (mm) | Bottom Dia. (mm) | Sheet Thickness (mm) | Base Plate mm (L x W x T) | Foundation Bolt (No. xDiaxmm) |
| KOP03 | 3 | 70 | 130 | 3 | 200 x 200 x 12 | 4 x 16 x 450 |
| KOP04 | 4 | 70 | 130 | 3 | 200 x 200 x 12 | 4 x 16 x 450 |
| KOP06 | 6 | 70 | 130 | 3 | 200 x 200 x 12 | 4 x 16 x 600 |
| KOP09 | 9 | 70 | 155 | 3 | 250 x 250 x 12 | 4 x 20 x 700 |
| KOP010 | 10 | 70 | 155 | 3 | 250 x 250 x 16 | 4 x 24 x 750 |
| KOP011 | 11 | 70 | 175 | 3 | 275 x 275 x 16 | 4 x 24 x 750 |
| KOP012 | 12 | 70 | 175 | 3 | 275 x 275 x 16 | 4 x 24 x 750 |
| KOP013 | 13 | 125 | 270 | 3 | 340 x 340 x 20 | 4 x 24 x 900 |
Additional Information:
Product Details:
| Pole Type | Octagonal Poles |
| Material | Mild Steel |
| Height | 8 Meter |
| Usage/Application | Highway |
| Surface Finish | Powder Coated, Hot Dip Galvanized |
| Bottom Size | 130/135 A/F mm |
| Plate Thickness Mm | 3 mm |
| Product Code | KOP08 |
| Top Size | 70 A/F mm |
| Base Plate Size | 220X220X12 mm |
| Pole Type | Height (Meter) | Top Diameter (mm) | Bottom Dia. (mm) | Sheet Thickness (mm) | Base Plate mm (L x W x T) | Foundation Bolt (No. xDiaxmm) |
| KOP03 | 3 | 70 | 130 | 3 | 200 x 200 x 12 | 4 x 16 x 450 |
| KOP04 | 4 | 70 | 130 | 3 | 200 x 200 x 12 | 4 x 16 x 450 |
| KOP05 | 5 | 70 | 130 | 3 | 200 x 200 x 12 | 4 x 16 x 450 |
| KOP06 | 6 | 70 | 130 | 3 | 200 x 200 x 12 | 4 x 16 x 600 |
| KOP09 | 9 | 70 | 155 | 3 | 250 x 250 x 12 | 4 x 20 x 700 |
| KOP010 | 10 | 70 | 155 | 3 | 250 x 250 x 16 | 4 x 24 x 750 |
| KOP011 | 11 | 70 | 175 | 3 | 275 x 275 x 16 | 4 x 24 x 750 |
| KOP012 | 12 | 70 | 175 | 3 | 275 x 275 x 16 | 4 x 24 x 750 |
| KOP013 | 13 | 125 | 270 | 3 | 340 x 340 x 20 | 4 x 24 x 900 |
Product Details:
| Pole Type | Octagonal Poles |
| Material | Mild Steel |
| Height | 9 Meter |
| Usage/Application | Highway |
| Surface Finish | Hot Dip Galvanized |
| Bottom Size | 155 A/F mm |
| Plate Thickness Mm | 3 mm |
| Top Size | 70 A/F mm |
| Base Plate Size | 250 x 250 x 12 mm (L x W x T) |
| Brand | Kasper |
| Product Code | KOP09 |
| Pole Type | Height (Meter) | Top Diameter (mm) | Bottom Dia. (mm) | Sheet Thickness (mm) | Base Plate mm (L x W x T) | Foundation Bolt (No. xDiaxmm) |
| KOP03 | 3 | 70 | 130 | 3 | 200 x 200 x 12 | 4 x 16 x 450 |
| KOP04 | 4 | 70 | 130 | 3 | 200 x 200 x 12 | 4 x 16 x 450 |
| KOP05 | 5 | 70 | 130 | 3 | 200 x 200 x 12 | 4 x 16 x 450 |
| KOP06 | 6 | 70 | 130 | 3 | 200 x 200 x 12 | 4 x 16 x 600 |
| KOP07 | 7 | 70 | 130 | 3 | 220 x 220 x 12 | 4 x 20 x 600 |
| KOP08 | 8 | 70 | 135 | 3 | 225 x 225 x 12 | 4 x 20 x 700 |
| KOP010 | 10 | 70 | 155 | 3 | 250 x 250 x 16 | 4 x 24 x 750 |
| KOP011 | 11 | 70 | 175 | 3 | 275 x 275 x 16 | 4 x 24 x 750 |
| KOP012 | 12 | 70 | 175 | 3 | 275 x 275 x 16 | 4 x 24 x 750 |
| KOP013 | 13 | 125 | 270 | 3 | 340 x 340 x 20 | 4 x 24 x 900 |
Product Details:
| Pole Type | Octagonal Poles |
| Material | Mild Steel |
| Height | 11 Meter |
| Usage/Application | Highway |
| Surface Finish | Hot Dip Galvanized |
| Bottom Size | 175 A/F mm |
| Plate Thickness Mm | 3 mm |
| Top Size | 70 A/F mm |
| Base Plate Size | 275 x 275 x 16 mm |
| Product Code | KOP011 |
| Pole Type | Height (Meter) | Top Diameter (mm) | Bottom Dia. (mm) | Sheet Thickness (mm) | Base Plate mm (L x W x T) | Foundation Bolt (No. xDiaxmm) |
| KOP03 | 3 | 70 | 130 | 3 | 200 x 200 x 12 | 4 x 16 x 450 |
| KOP04 | 4 | 70 | 130 | 3 | 200 x 200 x 12 | 4 x 16 x 450 |
| KOP05 | 5 | 70 | 130 | 3 | 200 x 200 x 12 | 4 x 16 x 450 |
| KOP06 | 6 | 70 | 130 | 3 | 200 x 200 x 12 | 4 x 16 x 600 |
| KOP09 | 9 | 70 | 155 | 3 | 250 x 250 x 12 | 4 x 20 x 700 |
| KOP010 | 10 | 70 | 155 | 3 | 250 x 250 x 16 | 4 x 24 x 750 |
| KOP012 | 12 | 70 | 175 | 3 | 275 x 275 x 16 | 4 x 24 x 750 |
| KOP013 | 13 | 125 | 270 | 3 | 340 x 340 x 20 | 4 x 24 x 900 |
Product Details:
| Minimum Order Quantity | 25 Piece |
| Pole Type | Octagonal |
| Material | Mild Steel |
| Height | 13 Meter |
| Usage/Application | Highway |
| Plate Thickness Mm | 3 mm |
| Surface Coating | Hot Dip Galvanized |
| Top Diameter | 125 mm |
| Bottom Diameter | 270 mm |
| Base Plate | 340 x 340 x 20 mm (L x W x T) |
| Product Code | KOP013 |
| Pole Type | Height (Meter) | Top Diameter (mm) | Bottom Dia. (mm) | Sheet Thickness (mm) | Base Plate mm (L x W x T) | Foundation Bolt (No. xDiaxmm) |
| KOP03 | 3 | 70 | 130 | 3 | 200 x 200 x 12 | 4 x 16 x 450 |
| KOP04 | 4 | 70 | 130 | 3 | 200 x 200 x 12 | 4 x 16 x 450 |
| KOP05 | 5 | 70 | 130 | 3 | 200 x 200 x 12 | 4 x 16 x 450 |
| KOP06 | 6 | 70 | 130 | 3 | 200 x 200 x 12 | 4 x 16 x 600 |
| KOP09 | 9 | 70 | 155 | 3 | 250 x 250 x 12 | 4 x 20 x 700 |
| KOP010 | 10 | 70 | 155 | 3 | 250 x 250 x 16 | 4 x 24 x 750 |
| KOP011 | 11 | 70 | 175 | 3 | 275 x 275 x 16 | 4 x 24 x 750 |
| KOP012 | 12 | 70 | 175 | 3 | 275 x 275 x 16 | 4 x 24 x 750 |
Additional Information:
Product Details:
| Minimum Order Quantity | 20 Piece |
| Pole Type | Octagonal Pole |
| Material | Iron |
| Brand | Kasper |
| Height | 7 Meter |
| Usage/Application | Highway |
| Surface Finish | Hot Dip Galvanized |
| Bottom Size | 130 A/F mm |
| Plate Thickness Mm | 3 mm |
| Top Size | 70 A/F mm |
| Base Plate Size | 220 x 220 x 12 mm (L x W x T) |
| Product Code | KOP07 |
| Country of Origin | Made in India |
| Pole Type | Height (Meter) | Top Diameter (mm) | Bottom Dia. (mm) | Sheet Thickness (mm) | Base Plate mm (L x W x T) | Foundation Bolt (No. xDiaxmm) |
| KOP03 | 3 | 70 | 130 | 3 | 200 x 200 x 12 | 4 x 16 x 450 |
| KOP04 | 4 | 70 | 130 | 3 | 200 x 200 x 12 | 4 x 16 x 450 |
| KOP05 | 5 | 70 | 130 | 3 | 200 x 200 x 12 | 4 x 16 x 450 |
| KOP06 | 6 | 70 | 130 | 3 | 200 x 200 x 12 | 4 x 16 x 600 |
| KOP08 | 8 | 70 | 135 | 3 | 225 x 225 x 12 | 4 x 20 x 700 |
| KOP09 | 9 | 70 | 155 | 3 | 250 x 250 x 12 | 4 x 20 x 700 |
| KOP010 | 10 | 70 | 155 | 3 | 250 x 250 x 16 | 4 x 24 x 750 |
| KOP011 | 11 | 70 | 175 | 3 | 275 x 275 x 16 | 4 x 24 x 750 |
| KOP012 | 12 | 70 | 175 | 3 | 275 x 275 x 16 | 4 x 24 x 750 |
| KOP013 | 13 | 125 | 270 | 3 | 340 x 340 x 20 | 4 x 24 x 900 |
Additional Information:
Product Details:
| Minimum Order Quantity | 1 Piece |
| Material | Mild Steel |
| Usage/Application | Highway |
| Shape | Octagonal |
| Surface Finish | Hot-Dip Galvanized |
| Design | Octagonal |
This 35 Meter High Mast Pole is manufactured from Mild Steel and its surface has smooth finish owing to paint coating.
The pole is Polygonal in shape and its usage is relevant for Street, Highways and to cover big area.
Additional Information:
